Module 4.1: Systems and Structures for Organizing Information

LIS 5043: Organization of Information

Dr. Manika Lamba

Introduction

• In Module 4 we will be examining different systems and how they are designed.

• We will look at ways in which we evaluate IR systems.

• Also, you will be learning more about how system design affects/impacts retrieval by users.

• Keep in mind that a user-centered system should be based on what we know about how users search for and use information sources.

• Think about HOW systems elements, metadata schemes, interfaces either enable or inhibit effective retrieval.

In Module 3, we talked about users and information seeking studies and information behavior research– different ways in which our field and other fields have modeled users.

In Module 4, we’re going to talk about information systems and databases, database design, and database modeling. We’re going to look at information systems from a basic system analysis perspective. I’m going to introduce you to some terminology–so you can better understand the vocabulary you may encounter in the readings and throughout Module 4.

We will not be getting into in-depth database design or system analysis in this module and will cover these topics on a very general level. If you are interested in these topics, I recommend you to enroll in LIS 4683 Database Design for Information Organization course!

But for this class, it’s important for us to understand how systems are structured and how that impacts some of the choices we make when we design our own systems or when we create representations within those systems.

You will also learn more about systems in LIS 5063 Fundamentals of Information Technology. However, the data modeling that we will do in this lecture and in the accompanying lecture will give you a jump start in developing information systems.

So, in this module, you’re going to be examining some different systems and how they’re designed. You’re going to be looking at different automated library systems. You’ll be looking at some digital library systems, and then using these different systems and evaluating them from a user’s perspective.

You also are going to be learning more about how system design affects and impacts retrieval by our users. You will consider how the choices we make when we’re setting up a database can impact the search and retrieval of our users.

I also want you to keep in mind that a user-centered system should be based on what we know about how users search for and use information sources. As you’re going through this part of the module, think about the last module and the information seeking studies that you encountered and learned about and the different models that LIS researchers have developed based upon how users interact with different systems.

I also want you to think about how systems’ elements, or the different aspects within the system, the different features, and the metadata schemes and the interface features either enable or inhibit effective retrieval.

When you complete AE#4 you’ll be evaluating the effectiveness of the system structure of three search interfaces. Think about user-centered systems. Think about how the choices you as the designer make can impact a user’s retrieval within that system and also their experience using the system. And think about how those different elements all work together to achieve a specific goal or purpose.

Information Systems

An information system comprises a set of resources for collecting, managing, and providing access to information

• These resources may involve:
  • manual technologies
  • automated technologies

To begin, a very basic definition of an information system is “an information system comprises a set of resources for collecting, managing, and providing access to information.”

And these resources may involve manual technologies and automated technologies.

So, we’re not just thinking about an online database when we’re talking about an information system.

We could be talking about file cabinets in your office, or we could talk about file folder systems within a human resources department. All of these are different kinds of information systems.

Information Containers and Content

• Information in an information system is in some tangible form – we can manipulate it

• Information objects have two aspects:

  • Information container: physical embodiment of information
  • Information content: intellectual contents of information object recorded in some fashion

• Many information systems utilize representations or surrogates of the information objects

• The surrogates are what get manipulated in most cases, but with Web, digital libraries, etc. we now access the object as well

We can also categorize information into two different buckets –containers and content–- we’ll revisit this idea several times throughout the semester.

Information in an information system is in some tangible form, meaning that we can manipulate it, we can organize it, we can move it around or change it if necessary.

‘In some tangible form’, means it can be in any form of object, virtual, electronic, digitized, print–doesn’t matter. The information is also what Buckland calls “information as thing” in the Buckland reading.

Information objects have two very basic aspects. They deal with the container aspects, or the physical aspects, of the information but they deal with the aspects of the object that describe the physical object rather than the other component, which is the content.

When we talk about information content in libraries and information science, we deal with the intellectual content, or what the object is about. In other words, what subject or representation of the author’s ideas has been recorded in some fashion within the object.

So, we have two buckets. We have a bucket for the container aspect and we have another bucket for the content aspect. In a few minutes we’ll talk about what would be included in each of those different areas.

Many information systems utilize representations to connect users with the objects. For example, a library card catalog, whether it’s in a print form in a set of drawers or it may be an online catalog, you’re actually accessing a representation of an object rather than the object.

So, a MARC catalog record or a library card catalog record are representations, or surrogates, of the object–not the actual object.

However, with the Web and digital collections, we now can access more than just the surrogate; we can access the object.

Systems and Systems Thinking

• System: Consists of a number of components working together to achieve some purpose
• Two important aspects
  • interacting components/subsystems
  • purposeful
• System concepts
  • Inputs
  • Transformation processes
  • Outputs
  • Feedback

Now, when we think about systems from a system analysis perspective, we drill down to the different components of a system. A system is defined as “consisting of a number of components that work together to achieve some purpose.” And again, this doesn’t just have to apply to technical systems only; this concept can apply to any kind of a system.

For example, in a school’s science textbook, the authors describe how organisms must align with their environment for the ecosystem to function properly. I hadn’t considered it as a system before, but suddenly, it clicks—like a lightbulb turning on.

In library and information science the system we’re most concerned about is an information retrieval system, or even a library integrated system. They have different components that work together to achieve a purpose, or a set of purposes.

Systems have different inputs, transformative processes, outputs, and feedback.

Four Components of an Information System

An information system is an socio-technical system comprised of two sub-systems: a technical sub-system and a social sub-system.

The technical sub-system encompasses the technology and process components, while the social sub-system encompasses the people and structure components.

Structure of Information System

For instance, this is a model of the components of a system.

The system has input from one side–people with problems and resulting information needs.

On the other side, the system has input that’s created by a cataloger or an indexer, where information professionals describe or create surrogates of the objects in the collection.

These representations are put into an information system, there’s a transformative process, or a retrieval matching process, and the output is information given back to the user that hopefully matches those two inputs.

So, from a systems perspective, an information system has one or more goals and objectives to perform.

Information System As a System

• Considered from a systems perspective, an information system has:
  • one or more goals and objectives
  • an environment
  • resources available to the system
  • processes or system components
  • management
• One system may be a subsystem for another system
  • library system as subsystem in university system
  • library catalog as subsystem in library system

A system exists within a specific environment, and it has specific resources allocated for its purposes. It has different processes and system components, and there’s always some kind of a management component–something that pulls everything together and makes sure the system works efficiently.

But again, these components will be different depending on the environment, depending upon the system , and the goals and purposes of that system.

Now, we can think of systems at many different levels, and they can also be part of a subsystem, meaning that a library is a subsystem in your university system or in your community–in your city or your county.

A library catalog is a subsystem in a library system. And even within our catalog there are different subsystems, such as circulation components, reference components, cataloging components, personnel components, etc., all within one integrated library system. All of these components work together to achieve particular purposes or goals.

Functions of Information Systems

• Selection
• Collection
• Storage
• Document Analysis & Representation
• File Organization
• Search Strategy & Retrieval
• Service/Dissemination

There are several functions for information systems. They can be used for selection purposes in the case of the library catalog. A user does some searching, finds a set of records, and selects items they find useful.

Systems can be used for collection purposes. They can illustrate and help us organize collections of items. They can be used for storage purposes. We store records of various different kinds. Systems can be used for document analysis and representation.

Our library catalogs can provide very useful information with reporting features. You can generate reports based on classification areas so you can weed your collections. The reports can be used for all kinds of different analyses. Systems can be used for file organization. And they can be used for search and retrieval, and service and dissemination.

So, these are just a few functions that come to mind right now of information systems, and I’m sure you can think of others that you’ve encountered with different systems you’ve used.

Information Retrieval Systems

• Components
  • Interface - to allow user to communicate with system
  • Database - to store representations or info objects
    • text
    • images
    • numeric data
  • Matching Component - to match representations

What we focus on in library and information science, as well as in this class, are information retrieval (IR) systems. Within an IR system, there are different components. The system has an interface, which allows our users to communicate with the system. The user has to know the language of the system–has to understand the messages that come back and also how to input information within the system.

A system has a database behind the interface, and this is where the system stores the representations of our information objects. Information objects are not just necessarily textual based; they can be images, they can be sound files, they can be numeric data. Any kind of object we can house in our library, we can create a representation for.

Also, an IR system has what is called a ‘matching component.’ This is the algorithms behind the scenes that make the information retrieval function work. The algorithms match the user’s search terms with the terms we’ve put in our library records or within our surrogates.

Database Terminology

• Database
  • Storage mechanism for data
  • Collection of logically related data
• Database Management System (DBMS)
  • Software for managing storage, organization, and retrieval of records from datbase
  • Provides for creation and maintenance of one or more databases
  • Examples: Oracle, Access, dBase, MySQL

Now let’s talk about databases. We’re going to examine the electronic kind of system that we use in libraries, that is behind the internet, or that is behind a lot of retrieval systems that we use today. A database is basically a storage mechanism for data. It has a collection of logically related data.

A database doesn’t have to be electronic. It can be a phone directory. Think about it. A phone directory gives you information about people. It gives you their names, their address, their phone number, right? And the next record in the phone book gives you exactly the same kind of information but for a different person or entity.

So, it contains logically related data about a particular set of individuals. It also provides business information and phone numbers for different businesses within a community. So, we can think of a database as being a phone directory. We can also about a file cabinet and all of its various different file folders as being a database–though if you look in my file cabinet, you would not see any kind of order at this point. It wouldn’t be a very logically related database.

We are going to focus mainly on the electronic database. There’s some terminology I want to introduce to you as we go along.

The first of those terms is what is called a ‘Database Management System,’ or a DBMS. The Bell readings give you some really nice examples and common language descriptions of various different kinds of databases that are available.

But a database management system or DBMS is software that we use for managing, storage, organization, and retrieval of records from databases. It provides for the creation and the maintenance of one or more databases. A couple of proprietary examples would be Oracle and Microsoft Access; while MySQL would be an example of an open source DBMS.

Database Design

• Three Levels/Stages of Design as Models
  • Conceptual Model
  • Logical Model
  • Physical Model
• From conceptualization to actual implementation

Database design involves what is called ‘data modelling’ or the process one engages in through the three stages of creation of a database structure or a metadata schema.

In the database modelling process there are three different levels or stages that one works through – the conceptual model, the logical model, and the physical model.

So, when we’re modeling a database generally you could be working with a group of people and have large pieces of paper out and modeling the whole structure of a database.

But you go from a conceptualization of what needs to be modeled and how to represent the items that you need to describe in the modeling, to the actual implementation of your model within a database management system.

So, let’s look at each of these stages individually.

Conceptual Level/Model

• Conceptual Level
  • Abstract view of real-world objects, processes or activities relevant to users
  • Geared toward representations of entities and relationships
• Entities
  • Distinct types of objects, bodies, agents
• Attributes
  • Characteristics or properties of entities
• Relationships
  • Meaningful associations between entities

At the conceptual level, this is where we start thinking about the collection; we start thinking about the objects in our collection. And we think about real world processes and activities that are relevant to the users of our particular collection and of the system we’re creating.

So, if we’re creating a human resources database for a corporation, we’re going to think about who would use this system–probably the people in HR, possibly the people in your company. What would some of your uses be? Well, to look up individual personnel records, to look at profiles, to look at employment history.

At the Conceptual level you start brainstorming about all the potential uses and users of a particular system. And you also try to get a really good idea of the different objects that are going to be present within that system or that collection.

This level is geared more to representations of what we call entities and relationships. Now, an ‘entity’ can be defined as a distinct type of object, body, or agent–something that we’re representing within a system.

Attributes, then, are very general characteristics or properties of the entities. So, if we’re working with a collection of books, the books themselves are the entities within our collection that we’re going to represent in some fashion. The attributes, then, are what we know–what the general characteristics are about those particular books. We’re going to come back to this in just a minute.

And then we start to model the different relationships that exist within and between the different entities.

Information Object Model

Here is a book. It represents the potential objects in our collection. It has a set of attributes. It has one or more creators associated with it. It has a name. It has one or more subjects. These are general characteristics or attributes of an object. Now, those attributes dealing with creator or name go into the physical container bucket. Those attributes dealing with subject go into the content or intellectual content bucket. So, we’re representing both sides of our basic structure in a representation by showing container and content attributes of an object.

This is just a basic example of how this would work. You obviously can think of other attributes that would be important to represent books within a collection.

Logical Level/Model

• Geared towards representation of entities as data
• File: collection of similarly structured records
• Record: basic unit within a file
  • Set of related data items, or information units
• Field: logical unit within a record
  • Spaces to receive data
• Data: information entered in fields
• Data Value: specific data entered in a field

The second level is the logical level; this level is concerned with representation of entities as data within our system. At this level or stage we start setting up a field structure based upon the attributes we’ve identified.

First, let’s introduce some more terminology relevant to this level.

A ‘file’ is considered a collection of similarly related records, or similarly structured records, meaning that the database has a file and within that file it contains the same data for every entity in our collection.

A ‘record’ is a basic unit within a file, and it has a set of related data items or information units. We have, again, very similar logically related data elements within a record. All of our records within our file contain the same elements. Then, within the record, there is a set of fields, and this is a logical unit within a record. The fields are the spaces that receive the data or where a cataloger/indexer records the data.

The ‘data’ is the information that we enter into each of the fields. You might also hear data referred to as a ‘data value’ or even a ‘value.’ It’s the specific data entered into a field.

Logical Model Example

So, for example, the database has a file. It contains four records–though this is a really small system with only four records. Within each of those records there is a similar structure. There are three fields–Title, Author, Subject,–but these fields are present in every record.

And then I put in one data value, ‘Twain,’ in the Author field in one record, which is one aspect of this particular item represented within our record. So, for this object, for this book, the author is Twain. We would also fill in the title and the subject and then we would have a completed record within this system structure.

Parallel Concepts

• Real life
  • Collection
  • Book
  • Author

• Conceptual
  • Set of Entities
  • Entity
  • Attribute

• Logical
  • File
  • Record
  • Field
  • Data value

The Organization of Information

Arlene G. Taylor

Let’s look at the data model from another perspective. In real life we have a collection. At the conceptual level, we have a set of entities. Okay? Our collection represents a set of entities. At the logical level, those entities are then represented within a file in our system. In real life we have a book; that’s the entity .

It’s represented in one or many records within a database. We have a creator or an author; this would be considered an attribute. It’s represented within one field, but could potentially be in many fields, within our system. And then the last entry on the slide, ‘The Organization of Information’ ‘Arlene G. Taylor,’ would be data or a data values within specific field(s).

Physical Level/Model

• Geared toward details of physical database implementation

• Includes specifications for fields, data, file organization and access, etc.

• Applies only to specific database

  • Conceptual and logical models may be implemented in different DBMS

The third level is the Physical Level. This level is geared towards determining and setting up the details of physical database implementation.

At this level we define each of the fields and the types of information they can include, any kind of structural exclusions that we want to make, and any kind of validation that we want to make as well.

So, we start looking at specifications for each field, such as data type, file organization, and accessibility, etc. These specifications usually only apply to the specific system you’re designing.

So, when you’re at this level, you’re thinking about how you’re going to implement the system within your database environment or DBMS.

Database Schema

• Defines a database’s structure
• Identifies details about the DB record:
  • fields
  • datatypes
  • value constraints
• Moves closer to the physical structure of the actual database implementation

The outcome of the physical level in the data modeling process is the creation of what is called a ‘database schema.’

The database schema defines the database’s structure; it determines very specific details about that particular database, which may be very different than other databases.

It identifies details about the database record, in terms of what fields are part of the record, and what data types will be captured within each of the fields.

So, for example, the designer would decide if the Author field is a text field. OR is it a field that will hold an image file or some other type of data?

We also make decisions at this point about what are called ‘value constraints,’ and we’ll talk about those in just a few moments. But the database schema moves us closer to the actual physical structure of the database implementation.

Record Structure

• Record structure reflects the needs of the data model
• Attributes become structured into one or more fields
• Specifications for each field determined
  • Fixed length or variable length
  • Type of data in field
  • Required, multiple entry
  • Content validation

At this point in the process, we have now what is considered the ‘record structure.’ The record structure reflects the needs that we interpreted based on the collection and the users that are now part of our data model. For example, you’ll see that your attributes now become structured into one or more fields as we looked at earlier.

We also have to decide on what are called ‘specifications’ for each field at this point. We look at whether or not a field is of a fixed length or of a variable length, meaning that we set the limit of the amount of characters that can be included in that field. Or if we allow it to be a variable length field, it means that from one record to another record that length of characters in that field can vary.

We also decide about the type of data that will be in the field as I mentioned a few minutes ago. We determine if it’s a text field, an image field, a numeric field, or if the field will hold some other type of data.

We also make decisions about whether it’s a required field, meaning that there always has to be a value entered into that field or you will not be allowed to save the record. Then another additional decision would be whether it’s a multiple entry field, or if that field can have more than one value within it. And then lastly, we make decisions about content validation, or whether or not we have a prescribed set of content that can be listed within the database field.

In the next few slides we’ll discuss each of these decisions in more depth.

We Make Decisions About …

• File type: type of data that goes into a field
  • Text, image, numeric
• Entry validation: controls number of entries in field
  • Required, unique, single
• Content Validation: limits data values that can be input in field. Often requires creation of list of authorized terms
  • Content validation list, controlled vocabulary, natural language

So, at this point we make a lot of decisions. We make decisions about file type. We have to look at what kind of data goes into each field. Is it a text field, is it an image field, does it contain numeric data, does it contain a sound file? We have to assign this data type, or file type to each field in our system. But when we’re conducting data modeling, we have to also sketch this out as well.

We make decisions about what’s called ‘entry validation.’ This is where we control the number of entries in a field. First of all, we have to decide “Is this field a required field?”–meaning that we always have to have a value in that field, or the system won’t save your record. There are very few fields that are actually required in systems, though if you have like an automatic ID number or something like that, that’s always a required field.

You have to decide if the value in that field is a unique value to that field within that system. And you have to decide how many entries can actually be input within that field. Is it a single value or a multiple value field?

We also make decisions about what’s called ‘content validation.’ This is where we can limit data values that can be input in the field. Now, in some systems you’ve seen a dropdown box or list when you’re searching that provides you with different types of publication or different formats. That’s an example of what might be content validation in the sense that you can only choose from those values for doing your searching. We can do the same thing when we’re setting up a field in a database.

If, for example, we have a Format field in the database and we want to decide exactly how those formats will be entered, we would add a content validation list, meaning that we restrict the form of the word or content in that field.

For example, if there are many different ways to spell out ‘DVD’–capitalized or not? –same with CD-ROM, we decide ahead of time the form of the word or the terms that are allowed in the field That way we have consistency in records, and it’s also a nice shortcut for the person creating the record because they just have to choose from a dropdown list. That’s an example of what we call ‘content validation.’

We Also Make Decision About …

• Indexing: adding values to the fields using specific criteria and rules, deciding if a field is searchable or not
  • Indexing a field makes it a searchable field in the system
  • A searchable field is considered an access point through which users can access the data in the fields of the records

We also make decisions about indexing. Now, indexing is probably one of the overused terms in our field and in information science as well; indexing has many different definitions depending on the purpose. In a database environment, when we say that we’re indexing something, that means we’re making it a searchable field. We’re instructing the system to index that field. And then, behind the scenes, the system creates a separate index for that field with all the values you put into that field. I’ll show you an example of an inverted index in a minute.

Now, in other contexts, indexing can mean subject representation; it can mean putting subject terms into a subject field in a database.

So, at this point, we’re talking about indexing in the sense that we’re making it a searchable field in our system, and therefore, what we call an access point to our users.

Indexing

• Indexing: Process of creating index for purpose of representing and providing access to information objects

  • May be performed by humans or computers
  • Determines how system searches field

• Index Entry: Any pointer or indicator included in an index

• Some choices:

  • Word: indexes and searches field by single words separately
  • Term/phrase: indexes and searches field by complete entry, all words together
  • Combination of Word/Phrase indexing

‘Indexing’ is defined in most contexts as the process of creating an index for the purpose of representing and providing access to information objects. It can be performed by humans–say if we’re creating a back of the book index or if we’re indexing a record in an online database–or it can be done automatically by computers. The computer generates the inverted index or the field specific index that is behind the database. The index entry contains two components:

1. a ‘pointer,’ usually the record ID of the record that contains the term or phrase, which directs the system to the record that includes the specific term, and

2. the word or phrase (called the index term), that is the data or value extracted from that field in each record. In the back of the book index, the pointer would be the page number(s).

The ‘indexing term,’ can be any word or phrase used for physical or subject description within the database fields. It can also be any word or phrase that a user inputs into a system to use for a search to retrieve documents. So, we use the term “indexing term” interchangeably. An ‘index term’ may also describe any attribute of the document, meaning it can be a value related to Author, Title, Year, Subject , etc.

So, indexing a field in a database, determines whether or not a field is searchable in the system, as well as how the values in the field are extracted and added to the inverted index.

There are two specifications a database designer will decide upon when setting up how a field will be indexed: Word and Phrase indexing.

‘Word indexing’ means that the field’s index is indexed and searched by single words separately. Every word you enter in a field is then set out separately in your index record.

If you set the field as ‘term or phrase,’ indexed that means the entry in the field is kept together as a phrase, at least as good as the system can determine that it’s a phrase. So, sometimes when a search results return hits that do not seem to match the query, this may be due to the indexing algorithm parsing apart an entry we meant to be a phrase.

Indexing Specification

Indexing Example

• Phrase Index

  • Complete User s Guide

  • Product Guide

  • Reference Manual

• Word Index

  • complete

  • guide

  • manual

  • product

  • reference

  • s

  • user

Here are some examples. Under the heading Phrase indexing: the inverted index would include the phrases ‘Complete User s Guide’–notice our punctuation has been stripped out. Systems doesn’t usually deal with punctuation–‘Product Guide,’ ‘Reference Guide.’

And then under the heading Word Index, the inverted index would include ‘complete,’ ‘guide,’ ‘manual,’ ‘product,’ ‘reference,’ ‘s,’ and ‘user’ set out separately. Now, how an inverted index is constructed can really impact retrieval if you’re searching by a word-by-word or phrase indexed field because you can end up with some really strange results based upon how you structure your search query.

But again, determining if a field is searchable or indexed, and the type of indexing, are choices we make when designing a database. We have to decide if we’re going to have a word or a phrase indexed field, and oftentimes we can do both.

Index File as Access Method

Index File: ordered (inverted) list of data entries drawn from one field in record

• Each index entry contains pointer to its record

• Index is specified during database creation
• Index entries are added automatically by database as data are entered in record fields
• Index file is linked to main file that contains records

So, to recap, an index file is an ordered or inverted list of data entries drawn from one field in the record.

So, we may have an author index, a title index, and/or a subject index if we decided those fields would be searchable.

Each index entry contains a pointer to a record, usually to the record ID. The index is specified during the database creation.

Index entries are added automatically by the database as data are entered into the record fields, or some systems will compile or re-index as a backup process at a scheduled time. The Index file is then linked to the main file that contains the records that you’re creating.

Filing Order Specifications

Index Specifications:

• Word by word: not letter by letter
• Ignore leading articles: a, an, the
• Ignores stop words
• Numbers file numerically: not alphabetically

Okay, on the previous couple of slides we looked at how an inverted index works behind the system and how your query terms are connected to the terms that are in the inverted index or indexes, depending on how a system is set up, for the different fields.

So, let’s talk now about some other additional index specifications, such as file ordering. These still remain important today even in full text systems, or full text IR systems, but they’re not quite as important as they used to be in flat file databases. We do, of course, have to specify when we create an index for a specific field whether we want it word-by-word or phrase-by-phrase, or our phrase index field.

But we also have to talk about things like ignoring leading articles, such as a, an, and the, or how the system will treat these when searching or sorting records. The main reason for this is not searching, but how the records are displayed back to our users.

So, we generally have within the index specifications that the field and the inverted index ignore the leading articles; basically, it just strips them out of a record. It also allows us to set up stop words. ‘Stop words’ are common words that are used repeatedly within systems that have very low value, so they’re stripped out.

They are words like prepositions; they’re words that are used so often that they lose any kind of retrieval value for a system. And so, stop words are generally ignored by a system. It’s a good idea as a searcher to see if you can locate the stop word list for a particular system, then you know to leave those words out of your query.

Also, systems number files numerically, not alphabetically unless you can change the default. So, again, file order specifications are not as important for searching, though in terms of stop words and leading articles, they do impact the query terms that you enter in a system. But they’re also important instructions to the system on how to display the results back to the users.

So What?

• Database specifications tell the system …
  • What types of data it contains
  • How to find data and records to retrieve
  • How to sort data
• Without specifications …
  • Every field would accept every kind of data
  • Meaningful operations (e.g., calculations) could not be performed on data
  • Retrieval would be slower and less effective

So, why is it important to understand how a system is set up and the decisions a designer makes?

The database specifications we mentioned earlier are instructions that we’re giving to the system. They tell the system about each individual field and the type of data that it contains so that the system can then know how to act on that data. It tells the system how to find data and records to retrieve by searching inverted indexes instead of a sequential search used in earlier systems. And it tells the system how to sort data.

When we start looking at MARC records, we’ll parse these concepts apart even further because MARC records still include delimiters and subfield codes, numeric or character codes, which are instructions to a system telling it how to parse the values within the fields.

So, even though these processes seem old, leftover from earlier days, they really are still very important to system functions. Without specification, every field would accept every kind of data. It would accept numeric data, text data, or image data.

So, you have to set your field up and specify to the DBMS what type of data should be recorded in that field. Also, again, as I said, meaningful operations cannot be performed on the data unless the field specifications have been set up. And, of course, this will impact retrieval; retrieval will be slower and less effective because the system won’t know how to treat the data in each of the fields.

How Does this Relate to Retrieval?

• How do we get the data out of the database?
• The organization of records within a file holds the key!
• Some methods in finding location of record:
  • Sequential search of records in the file (old method)
  • Inverted index (most common)
  • Full text algorithms (common in many systems)
• For bibliographic records, we often have multiple inverted indexes – provides for searchable fields.

How is this related to information retrieval or to the organization of information? The organization of records within a file is really the key to how information is accessible for the users. You will recall one of the specifications we have to decide about is whether or not a field is indexed. If you’ve indexed a field, then that field is searchable. So, organization of those records is really the key to retrieval.

There are different methods that have been used in the past and those that are more common today for finding information within your records. In the past, it was a sequential search of records in the file.

So, it would search every record in every field in every file, and as you can guess, that would take a very long time to retrieve information and to bring records back for the users.

We have just discussed how an inverted index is created. And in a few minutes, I’ll show you an example of how the process of searching an index works. An inverted index within a relational database environment is the most common form of retrieval, though this is shifting now to more full text algorithms that search the entire text of the text fields in you document, well usually what is actually searched is the first 245 significant characters; however, this is shifting now also as system algorithms become more powerful. So, it’s becoming more common to have full text searching in systems as well as inverted index searching.

In bibliographic records we often have multiple inverted indexes which provides for many searchable fields. So, when you search in a library card catalog and you search within the Author field or the Title field, you are indeed searching the inverted index for that field. So, instead of searching every field in every record of that database–of the library catalog database,–you’re searching only those fields that you have chosen.

Index File Example

Record structure: RecordID = key (linking) field

Let’ look at an example of how searching an inverted index works.

Here’s an example. This is an example of a basic representation in a card catalog record. There are four fields. There is a record ID, which tells the user “this is the ID for this record in this system.”

There are also Title, Author, and Subject fields. The record ID system in most databases is generally what is called a ‘key’ or a ‘linking field.’

In a database it also serves as the “pointer” in the inverted index.

Index File Example

In this system we have three records. These would be the representations of the items in the collection.

When we do a search–say we’re looking for ‘Peters’ in the Author field, the search results bring us back the pointer number two, which is the IR for Users by E. Peters.

So, our search is successful.

Index File Example

1. Search term matches index entry (data value)
2. Index entry points/links to record using key field
3. Record is retrieved that contains data value

Same thing for ‘Taylor’ or ‘Gorman’ if we’re searching in the Author index. If we’re searching in the Subject index and we search for ‘IR,’ we should get back record two because IR is within the subject field in that record, and it doesn’t exist in the Subject field in the other records.

This is a very basic example of how an inverted index works when searched within the system. Refer to the Bell readings for more examples.

Databases We Know

Now let’s look at some databases that you might know. I’m using as an example on this slide the University of Oklahoma Libraries, which you’ve probably already used at some point.

What you can see on the screen here is an example of my book called “Text Mining for Information Professionals: An Uncharted Territory”.

If you look at the record, you can begin to see the underlying structure, or the database schema, behind this particular system. This has basic information, such as title, author, publication information, physical description, and even a contents field.

You also can see that OU Libraries is using a particular vocabulary to assign subject terms to this particular resource in this system. There’s also additional information as to how we can find this resource within the collection, how many copies they own, what type of material it is, and whether or not it’s actually in use or available for check out.

You can see from this particular record that you have a lot of options when you’re searching. You can search by author, title. You can search by publisher if you knew the publisher. You can search by contents or subject terms. If your system allows, you can even search by call number if you know the call number assigned to a particular resource.

MARC View

This is the same book but with a different record structure.What you see here is the MARC record for this particular resource.

In the earlier slide we saw the same resource, but we saw all of the MARC fields converted into more user-friendly field labels, which is an option you or your system admin will specify when you set up your OPAC system.

You would still have probably the same functionality in terms of searching within the MARC system, but your search would be conducted differently than we saw in the OPAC because of the way that the system is structured. However, if you look closer, you can see that the same data has been entered into these fields.

So, it’s the same structure underlying the OPAC record, but the user view is very different in the view on the previous slide than what we see in a MARC record structure on this slide.

Databases We Know: Amazon

On this slide, I’m giving you another view of another object within a database. This record is within Amazon’s database.

You have Product Description, or Details, such as your format which would be paperback, how many pages, publisher, language, ISBN numbers, dimensions, shipping weight, etc.

In Amazon’s database, you have the title and the author information on an earlier portion of the webpage, which I’m not showing you here because I wanted to show you some additional features that we didn’t see in our other two records. This record has Editorial Reviews, Product Description, and links out to the author’s page, as well as additional customer reviews.

Some newer generation OPACs are adding in some of these features, where a user can comment or review a particular resource, or add subject tags if they like to a particular resource’s record.

Again, these options are in the newer OPACs, and not every library OPAC includes this information or the option for users to add reviews, tags, etc. But again, looking at this particular slide, you can see the field structure that is present within this database.

And even though each system is describing the same resource, there is different kinds of information that is displayed back to the users. In effect, there are different search options for a user within this system.

What TO DO Next

• After reviewing this lecture, please proceed to the Data Modeling lecture (Forever Frogs)

• Complete the data modeling exercise by working through the Data Modeling (Forever Frogs) presentation & worksheet

After you have completed this lecture, please review the Forever Frogs (FF) data modeling lecture in Canvas. The FF lecture will walk you through the data modeling process.

The FF lecture will help you better understand how to move through the data modeling process to identify attributes of your objects, develop field names and make decisions of the types of data and any data requirements (required, unique, indexed).

I hope you enjoy learning how systems are structured and how the decisions you make affect representations and retrieval.
